SPECIFICATIONS AND TECHNICAL DATA
| TYPE | CODE | DISPLACEMENT cm3 |
A mm |
B mm |
C INLET | D OUTLET | WEIGHT kg |
| FZ0 15 | 200FZ0015D0200FZ0015S0 | 15 | 96,5 | 142,5 | 3/4 | 1/2 | 8,4 |
| FZ0 22 | 200FZ0022D0200FZ0022S0 | 22 | 99,5 | 147,5 | 3/4 | 1/2 | 8,9 |
| FZ0 27 | 200FZ0027D0200FZ0027S0 | 27 | 105 | 152,5 | 3/4 | 1/2 | 9 |
| FZ0 36 | 200FZ0036D0200FZ0036S0 | 36 | 101,5 | 157,5 | 3/4 | 1/2 | 9,1 |
| FZ0 43 | 200FZ0043D0200FZ0043S0 | 43 | 104,5 | 162,5 | 1 | 3/4 | 10,2 |
| FZ0 57 | 200FZ0057D0200FZ0057S0 | 57 | 111,5 | 172,5 | 1 | 3/4 | 11,1 |
| FZ0 65 | 200FZ0065D0200FZ0065S0 | 65 | 116,5 | 177,5 | 1 | 3/4 | 11,5 |
| FZ0 90 | 200FZ0090D0200FZ0090S0 | 84 | 126 | 192,5 | 1 1/4 | 1 | 12,6 |
